The Monark 700 is a 22.51ft fractional sloop designed by Peter Norlin and built in fiberglass between 1978 and 1982.
200 units have been built.
The Monark 700 is a light sailboat which is a reasonably good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Monark 700 | ||
| Length | 22.51 ft | ||
| Beam | 7.32 ft | ||
| Draft | 4.53 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.03 | ||
| Ballast / displ. | 39.31 % | ||
| Displ. / length | 184.38 | ||
| Comfort ratio | 16.45 | ||
| Capsize | 2.01 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 19.55 ft | ||
| Maximum draft | 4.53 ft | ||
| Displacement | 3086 lbs | ||
| Ballast | 1213 lbs | ||
| Hull speed | 5.92 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 225 sq.ft | ||
| Air draft | 36.10 ft | ||
| Sail area fore | 103.81 sq.ft | ||
| Sail area main | 121.18 sq.ft | ||
| I | 25.92 ft | ||
| J | 8.01 ft | ||
| P | 27.89 ft | ||
| E | 8.69 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Peter Norlin | ||
| First built | 1978 | ||
| Last built | 1982 | ||
| Number built | 200 |
