The Mg 26 peterson is a 25.16ft masthead sloop designed by Doug Peterson and built in fiberglass by Northshore Yachts (UK) since 1972.
The Mg 26 peterson is a light sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. There is a very short water supply range.
Main features
| Model | Mg 26 peterson | ||
| Length | 25.16 ft | ||
| Beam | 9.42 ft | ||
| Draft | 5.09 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 34.51 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 106.05 | ||
| Comfort ratio | 7.70 | ||
| Capsize | 2.90 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 21 ft | ||
| Maximum draft | 5.09 ft | ||
| Displacement | 2200 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 6.14 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 364 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Northshore Yachts (UK) | ||
| Designer | Doug Peterson | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
