The Maxi 909 is a 29.53ft fractional sloop designed by Pelle Petterson and built in fiberglass by Maxi Yachts (SWE) between 1986 and 1991.
210 units have been built.
The Maxi 909 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Maxi 909 | ||
| Length | 29.53 ft | ||
| Beam | 10.10 ft | ||
| Draft | 5.41 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.63 | ||
| Ballast / displ. | 42.18 % | ||
| Displ. / length | 211.31 | ||
| Comfort ratio | 19.21 | ||
| Capsize | 2.11 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 24.61 ft | ||
| Maximum draft | 5.41 ft | ||
| Displacement | 7055 lbs | ||
| Ballast | 2976 lbs | ||
| Hull speed | 6.65 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 404 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 172.78 sq.ft | ||
| Sail area main | 230.98 sq.ft | ||
| I | 32.91 ft | ||
| J | 10.50 ft | ||
| P | 36.09 ft | ||
| E | 12.80 ft |
Engine
| Nb engines | 1 | ||
| Total power | 9 HP | ||
| Fuel capacity | 9 gals |
Accommodations
| Water capacity | 24 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Maxi Yachts (SWE) | ||
| Designer | Pelle Petterson | ||
| First built | 1986 | ||
| Last built | 1991 | ||
| Number built | 210 |
