The Maxi 84 is a 28.02ft masthead sloop designed by Pelle Petterson and built in fiberglass by Börjesson Brothers between 1977 and 1983.
1350 units have been built.
The Maxi 84 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Maxi 84 | ||
| Length | 28.02 ft | ||
| Beam | 9.68 ft | ||
| Draft | 4.92 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.65 | ||
| Ballast / displ. | 45 % | ||
| Displ. / length | 224.07 | ||
| Comfort ratio | 19.93 | ||
| Capsize | 2.07 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23.62 ft | ||
| Maximum draft | 4.92 ft | ||
| Displacement | 6614 lbs | ||
| Ballast | 2976 lbs | ||
| Hull speed | 6.51 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 387.50 sq.ft | ||
| Air draft | 38.22 ft | ||
| Sail area fore | 204.27 sq.ft | ||
| Sail area main | 147.04 sq.ft | ||
| I | 36.09 ft | ||
| J | 11.32 ft | ||
| P | 32 ft | ||
| E | 9.19 ft |
Engine
| Nb engines | 1 | ||
| Total power | 13 HP | ||
| Fuel capacity | 9 gals |
Accommodations
| Water capacity | 24 gals | ||
| Headroom | 6.04 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Börjesson Brothers | ||
| Designer | Pelle Petterson | ||
| First built | 1977 | ||
| Last built | 1983 | ||
| Number built | 1350 |
