Malo 116
The Malo 116 is a 38.06ft masthead sloop designed by Olsöners Båtbyggen and built in fiberglass by Malö Yachts (SWE) between 1980 and 1990.
90 units have been built.
The Malo 116 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a good water supply range.
Malo 116 for sale elsewhere on the web:
Main features
| Model | Malo 116 | ||
| Length | 38.06 ft | ||
| Beam | 12 ft | ||
| Draft | 5.58 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.91 | ||
| Ballast / displ. | 43.91 % | ||
| Displ. / length | 251.64 | ||
| Comfort ratio | 28.29 | ||
| Capsize | 1.89 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 30.84 ft | ||
| Maximum draft | 5.58 ft | ||
| Displacement | 16534 lbs | ||
| Ballast | 7260 lbs | ||
| Hull speed | 7.44 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 724 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 402.51 sq.ft | ||
| Sail area main | 321.71 sq.ft | ||
| I | 51.67 ft | ||
| J | 15.58 ft | ||
| P | 45.60 ft | ||
| E | 14.11 ft |
Engine
| Nb engines | 1 | ||
| Total power | 36 HP | ||
| Fuel capacity | 58 gals |
Accommodations
| Water capacity | 132 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Malö Yachts (SWE) | ||
| Designer | Olsöners Båtbyggen | ||
| First built | 1980 | ||
| Last built | 1990 | ||
| Number built | 90 |
Other photos
