The Maine cat 30 is a 30.0ft frac. sloop (rotating spar) designed by Dick Vermuelen and built in fiberglass by Maine Cat since 2001.
The Maine cat 30 is a light sailboat which is a very high performer. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Maine cat 30 | ||
| Length | 30 ft | ||
| Beam | 18 ft | ||
| Draft | 2 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 24.30 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 107.03 | ||
| Comfort ratio | 6.70 | ||
| Capsize | 3.96 |
Hull
| Hull type | Catamaran twin daggerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 29.25 ft | ||
| Maximum draft | 5 ft | ||
| Displacement | 6000 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 7.25 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Frac. Sloop (Rotating Spar) | ||
| Sail area (100%) | 500 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 26 gals |
Accommodations
| Water capacity | 54 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Maine Cat | ||
| Designer | Dick Vermuelen | ||
| First built | 2001 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
