The Macgregor 26d is a 25.83ft fractional sloop designed by Roger MacGregor and built in fiberglass by Macgregor Yacht Corp between 1986 and 1989.
The Macgregor 26d is an ultralight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Macgregor 26d | ||
| Length | 25.83 ft | ||
| Beam | 7.92 ft | ||
| Draft | 1.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.83 | ||
| Ballast / displ. | 42.11 % | ||
| Displ. / length | 98.04 | ||
| Comfort ratio | 11.56 | ||
| Capsize | 2.24 |
Hull
| Hull type | Daggerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 23.50 ft | ||
| Maximum draft | 5.33 ft | ||
| Displacement | 2850 lbs | ||
| Ballast | 1200 lbs | ||
| Hull speed | 6.50 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 236 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Macgregor Yacht Corp | ||
| Designer | Roger MacGregor | ||
| First built | 1986 | ||
| Last built | 1989 | ||
| Number built | 0 | ?? |
