The Lord helmsman is a 31.33ft fractional sloop designed by Håkan Södergren and built in fiberglass by Helmsman Yachts between 1978 and 1988.
90 units have been built.
The Lord helmsman is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Lord helmsman | ||
| Length | 31.33 ft | ||
| Beam | 9.78 ft | ||
| Draft | 4.92 ft | ||
| Country | Denmark (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.92 | ||
| Ballast / displ. | 51.02 % | ||
| Displ. / length | 299.22 | ||
| Comfort ratio | 29.57 | ||
| Capsize | 1.77 |
Hull
| Hull type | Monohull long keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 25.26 ft | ||
| Maximum draft | 4.92 ft | ||
| Displacement | 10803 lbs | ||
| Ballast | 5512 lbs | ||
| Hull speed | 6.73 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 454 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 221.56 sq.ft | ||
| Sail area main | 232.48 sq.ft | ||
| I | 38.60 ft | ||
| J | 11.48 ft | ||
| P | 39.37 ft | ||
| E | 11.81 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Helmsman Yachts | ||
| Designer | Håkan Södergren | ||
| First built | 1978 | ||
| Last built | 1988 | ||
| Number built | 90 |
