Lindenberg 22 mt
The Lindenberg 22 mt is a 21.5ft fractional sloop designed by Bruce Kelly/Paul Lindenberg and built in fiberglass by Lindenberg Yachts since 1978.
The Lindenberg 22 mt is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Lindenberg 22 mt for sale elsewhere on the web:
Main features
| Model | Lindenberg 22 mt | ||
| Length | 21.50 ft | ||
| Beam | 8 ft | ||
| Draft | 0.75 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 23.84 | ||
| Ballast / displ. | 44.44 % | ||
| Displ. / length | 156.55 | ||
| Comfort ratio | 9.41 | ||
| Capsize | 2.63 |
Hull
| Hull type | Monohull swing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 17.25 ft | ||
| Maximum draft | 4.67 ft | ||
| Displacement | 1800 lbs | ||
| Ballast | 800 lbs | ||
| Hull speed | 5.57 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 220 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 81.56 sq.ft | ||
| Sail area main | 132.50 sq.ft | ||
| I | 22.50 ft | ||
| J | 7.25 ft | ||
| P | 26.50 ft | ||
| E | 10 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Lindenberg Yachts | ||
| Designer | Bruce Kelly/Paul Lindenberg | ||
| First built | 1978 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
