The Lagoon 42 is a 42.5ft fractional sloop designed by Van Peteghem/Lauriot-Prevost and built in fiberglass by TPI Composites between 1990 and 1994.
51 units have been built.
The Lagoon 42 is a light sailboat which is a very high performer. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Lagoon 42 | ||
| Length | 42.50 ft | ||
| Beam | 22.67 ft | ||
| Draft | 4.42 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 27.67 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 126.98 | ||
| Comfort ratio | 10.06 | ||
| Capsize | 3.56 |
Hull
| Hull type | Catamaran Twin Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 38.75 ft | ||
| Maximum draft | 4.42 ft | ||
| Displacement | 16550 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 8.34 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1119 sq.ft | ||
| Air draft | 56.82 ft | ||
| Sail area fore | 334.58 sq.ft | ||
| Sail area main | 345.88 sq.ft | ||
| I | 48.56 ft | ||
| J | 13.78 ft | ||
| P | 50.20 ft | ||
| E | 13.78 ft |
Engine
| Nb engines | 1 | ||
| Total power | 54 HP | ||
| Fuel capacity | 80 gals |
Accommodations
| Water capacity | 160 gals | ||
| Headroom | 6.25 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | TPI Composites | ||
| Designer | Van Peteghem/Lauriot-Prevost | ||
| First built | 1990 | ||
| Last built | 1994 | ||
| Number built | 51 |
