The Krammer 700 is a 23.2ft masthead sloop designed by Richard Lefeber and built in fiberglass between 1970 and 1977.
100 units have been built.
The Krammer 700 is a moderate weight sailboat which is under powered. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Krammer 700 | ||
| Length | 23.20 ft | ||
| Beam | 8.96 ft | ||
| Draft | 2.46 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 8.20 | ||
| Ballast / displ. | 35.72 % | ||
| Displ. / length | 283.97 | ||
| Comfort ratio | 23.48 | ||
| Capsize | 1.96 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 21.33 ft | ||
| Maximum draft | 2.46 ft | ||
| Displacement | 6173 lbs | ||
| Ballast | 2205 lbs | ||
| Hull speed | 6.19 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 172 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 20 HP | ||
| Fuel capacity | 11 gals |
Accommodations
| Water capacity | 32 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Richard Lefeber | ||
| First built | 1970 | ||
| Last built | 1977 | ||
| Number built | 100 |
