The King arthur 35 is a 35.5ft masthead sloop designed by Walter F. Rayner and built in wood by Custom craft since 1956.
The King arthur 35 is a heavy sailboat which is a reasonably good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat.
Main features
| Model | King arthur 35 | ||
| Length | 35.50 ft | ||
| Beam | 9.33 ft | ||
| Draft | 5.25 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.97 | ||
| Ballast / displ. | 41.67 % | ||
| Displ. / length | 342.86 | ||
| Comfort ratio | 33.64 | ||
| Capsize | 1.63 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Wood | ||
| Waterline length | 25 ft | ||
| Maximum draft | 5.25 ft | ||
| Displacement | 12000 lbs | ||
| Ballast | 5000 lbs | ||
| Hull speed | 6.70 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 554 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 24 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Custom craft | ||
| Designer | Walter F. Rayner | ||
| First built | 1956 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
