The Juno is a 22.24ft gaffhead sloop designed by E.G. van de Stadt and built in plywood since 1951.
The Juno is a moderate weight sailboat which is slightly under powered. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Juno | ||
| Length | 22.24 ft | ||
| Beam | 6.56 ft | ||
| Draft | 3.12 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.94 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 242.11 | ||
| Comfort ratio | 20.37 | ||
| Capsize | 1.80 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Plywood | ||
| Waterline length | 17.88 ft | ||
| Maximum draft | 3.12 ft | ||
| Displacement | 3100 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 5.67 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Gaffhead Sloop | ||
| Sail area (100%) | 198 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | E.G. van de Stadt | ||
| First built | 1951 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
