The Jpk 1080 is a 35.43ft fractional (9/10) sloop designed by Jacques Valer and built in carbon fiber or composite by JPK Composites since 2013.
The Jpk 1080 is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally small. There is a very short water supply range.
Main features
| Model | Jpk 1080 | ||
| Length | 35.43 ft | ||
| Beam | 11.97 ft | ||
| Draft | 7.22 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 23.45 | ||
| Ballast / displ. | 45.26 % | ||
| Displ. / length | 159.38 | ||
| Comfort ratio | 18.41 | ||
| Capsize | 2.19 |
Hull
| Hull type | Monohull fin keel with bulb and dual rudders | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 30.84 ft | ||
| Maximum draft | 7.22 ft | ||
| Displacement | 10472 lbs | ||
| Ballast | 4740 lbs | ||
| Hull speed | 7.44 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional (9/10) Sloop | ||
| Sail area (100%) | 699 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 20 gals |
Accommodations
| Water capacity | 32 gals | ||
| Headroom | 6.30 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | JPK Composites | ||
| Designer | Jacques Valer | ||
| First built | 2013 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
