The Jouet 760 is a 24.93ft masthead sloop designed by Philippe Briand and built in fiberglass by Yachting France (FRA) between 1982 and 1986.
150 units have been built.
The Jouet 760 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Jouet 760 | ||
| Length | 24.93 ft | ||
| Beam | 9.20 ft | ||
| Draft | 5.25 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.47 | ||
| Ballast / displ. | 40.91 % | ||
| Displ. / length | 223.11 | ||
| Comfort ratio | 17.40 | ||
| Capsize | 2.17 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21.33 ft | ||
| Maximum draft | 5.25 ft | ||
| Displacement | 4850 lbs | ||
| Ballast | 1984 lbs | ||
| Hull speed | 6.19 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 277 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 162.50 sq.ft | ||
| Sail area main | 114.84 sq.ft | ||
| I | 32.50 ft | ||
| J | 10 ft | ||
| P | 26.40 ft | ||
| E | 8.70 ft |
Engine
| Nb engines | 1 | ||
| Total power | 9 HP | ||
| Fuel capacity | 7.92 gals |
Accommodations
| Water capacity | 21.13 gals | ||
| Headroom | 5.90 ft | ||
| Nb of cabins | 1 | ||
| Nb of berths | 0 | ||
| Nb heads | 1 |
Builder data
| Builder | Yachting France (FRA) | ||
| Designer | Philippe Briand | ||
| First built | 1982 | ||
| Last built | 1986 | ||
| Number built | 150 |
