The Jeanneau yachts 57 is a 58.33ft fractional sloop designed by Philippe Briand and built in fiberglass by Jeanneau (FRA) between 2009 and 2015.
The Jeanneau yachts 57 is a moderate weight sailboat which is slightly under powered. It is not stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is good. There is an excellent water supply range.
Main features
| Model | Jeanneau yachts 57 | ||
| Length | 58.33 ft | ||
| Beam | 16.33 ft | ||
| Draft | 6.83 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.96 | ||
| Ballast / displ. | 22.48 % | ||
| Displ. / length | 209.43 | ||
| Comfort ratio | 42.51 | ||
| Capsize | 1.67 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 50.33 ft | ||
| Maximum draft | 6.83 ft | ||
| Displacement | 59810 lbs | ||
| Ballast | 13448 lbs | ||
| Hull speed | 9.51 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1423 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 751.28 sq.ft | ||
| Sail area main | 672.06 sq.ft | ||
| I | 68.83 ft | ||
| J | 21.83 ft | ||
| P | 64.25 ft | ||
| E | 20.92 ft |
Engine
| Nb engines | 1 | ||
| Total power | 140 HP | ||
| Fuel capacity | 115 gals |
Accommodations
| Water capacity | 246 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Philippe Briand | ||
| First built | 2009 | ||
| Last built | 2015 | ||
| Number built | 0 | ?? |
