The Javelin 30 parker is a 30.5ft masthead sloop designed by Fred R. Parker and built in fiberglass by Marine Construction Ltd. (UK) since 1971.
The Javelin 30 parker is a moderate weight sailboat which is under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small.
Main features
| Model | Javelin 30 parker | ||
| Length | 30.50 ft | ||
| Beam | 9 ft | ||
| Draft | 5 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 12.48 | ||
| Ballast / displ. | 47.92 % | ||
| Displ. / length | 281.74 | ||
| Comfort ratio | 22.66 | ||
| Capsize | 1.91 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 22 ft | ||
| Maximum draft | 5 ft | ||
| Displacement | 6720 lbs | ||
| Ballast | 3220 lbs | ||
| Hull speed | 6.29 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 277 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 20 HP | ||
| Fuel capacity | 10 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Marine Construction Ltd. (UK) | ||
| Designer | Fred R. Parker | ||
| First built | 1971 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
