The Islander 30 is a 29.58ft masthead sloop designed by J.H.McGlasson and built in fiberglass by Islander / Tradewind Yachts since 1968.
The Islander 30 is a moderate weight sailboat which is under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Islander 30 | ||
| Length | 29.58 ft | ||
| Beam | 8.83 ft | ||
| Draft | 3.67 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 13.79 | ||
| Ballast / displ. | 34.52 % | ||
| Displ. / length | 295.32 | ||
| Comfort ratio | 28.30 | ||
| Capsize | 1.74 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Fiberglass | ||
| Waterline length | 23.33 ft | ||
| Maximum draft | 3.67 ft | ||
| Displacement | 8400 lbs | ||
| Ballast | 2900 lbs | ||
| Hull speed | 6.47 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 355 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 177.12 sq.ft | ||
| Sail area main | 178.13 sq.ft | ||
| I | 32.80 ft | ||
| J | 10.80 ft | ||
| P | 28.50 ft | ||
| E | 12.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Islander / Tradewind Yachts | ||
| Designer | J.H.McGlasson | ||
| First built | 1968 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
