The Island packet 45 is a 45.25ft cutter designed by Robert K. Johnson and built in fiberglass by Island Packet Yachts between 1996 and 2000.
42 units have been built.
The Island packet 45 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is good. There is an excellent water supply range.
Main features
| Model | Island packet 45 | ||
| Length | 45.25 ft | ||
| Beam | 13.33 ft | ||
| Draft | 4.83 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.98 | ||
| Ballast / displ. | 44.01 % | ||
| Displ. / length | 238.89 | ||
| Comfort ratio | 34.96 | ||
| Capsize | 1.75 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 37.58 ft | ||
| Maximum draft | 4.83 ft | ||
| Displacement | 28400 lbs | ||
| Ballast | 12500 lbs | ||
| Hull speed | 8.21 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 1100 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 508.01 sq.ft | ||
| Sail area main | 414.14 sq.ft | ||
| I | 54.92 ft | ||
| J | 18.50 ft | ||
| P | 47.33 ft | ||
| E | 17.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 62 HP | ||
| Fuel capacity | 140 gals |
Accommodations
| Water capacity | 240 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Island Packet Yachts | ||
| Designer | Robert K. Johnson | ||
| First built | 1996 | ||
| Last built | 2000 | ||
| Number built | 42 |
