The Island packet 29 is a 29.0ft cutter designed by Bob Johnson and built in fiberglass by Island Packet Yachts between 1991 and 1997.
64 units have been built.
The Island packet 29 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Island packet 29 | ||
| Length | 29 ft | ||
| Beam | 10.83 ft | ||
| Draft | 4.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.04 | ||
| Ballast / displ. | 44.04 % | ||
| Displ. / length | 290.72 | ||
| Comfort ratio | 26.51 | ||
| Capsize | 1.96 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 25.58 ft | ||
| Maximum draft | 4.25 ft | ||
| Displacement | 10900 lbs | ||
| Ballast | 4800 lbs | ||
| Hull speed | 6.78 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 491 sq.ft | ||
| Air draft | 44 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 14 ft | ||
| P | 0 ft | ?? | |
| E | 12.25 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 23 gals |
Accommodations
| Water capacity | 45 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Island Packet Yachts | ||
| Designer | Bob Johnson | ||
| First built | 1991 | ||
| Last built | 1997 | ||
| Number built | 64 |
