The Irwin 32 is a 32.0ft masthead sloop designed by Ted Irwin and built in fiberglass by Irwin Yachts between 1970 and 1974.
The Irwin 32 is a heavy sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat.
Main features
| Model | Irwin 32 | ||
| Length | 32 ft | ||
| Beam | 9.67 ft | ||
| Draft | 3.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.69 | ||
| Ballast / displ. | 43.48 % | ||
| Displ. / length | 328.57 | ||
| Comfort ratio | 31.93 | ||
| Capsize | 1.72 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 25 ft | ||
| Maximum draft | 7.83 ft | ||
| Displacement | 11500 lbs | ||
| Ballast | 5000 lbs | ||
| Hull speed | 6.70 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 498 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 256.75 sq.ft | ||
| Sail area main | 241.50 sq.ft | ||
| I | 39.50 ft | ||
| J | 13 ft | ||
| P | 34.50 ft | ||
| E | 14 ft |
Engine
| Nb engines | 1 | ||
| Total power | 30 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Irwin Yachts | ||
| Designer | Ted Irwin | ||
| First built | 1970 | ||
| Last built | 1974 | ||
| Number built | 0 | ?? |
