The Irwin 27 is a 27.08ft masthead sloop designed by Ted Irwin and built in fiberglass by Irwin Yachts since 1967.
The Irwin 27 is a heavy sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Irwin 27 | ||
| Length | 27.08 ft | ||
| Beam | 8.67 ft | ||
| Draft | 2.67 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.24 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 342.01 | ||
| Comfort ratio | 25.55 | ||
| Capsize | 1.85 |
Hull
| Hull type | Monohull keel and centerboard with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20.50 ft | ||
| Maximum draft | 7.83 ft | ||
| Displacement | 6600 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 6.07 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 356 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 178.50 sq.ft | ||
| Sail area main | 193.98 sq.ft | ||
| I | 34 ft | ||
| J | 10.50 ft | ||
| P | 31.67 ft | ||
| E | 12.25 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Irwin Yachts | ||
| Designer | Ted Irwin | ||
| First built | 1967 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
