The Hylas 54 is a 54.08ft cutter designed by German Frers and built in fiberglass by Queen Long Marine since 1999.
The Hylas 54 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Hylas 54 | ||
| Length | 54.08 ft | ||
| Beam | 15.75 ft | ||
| Draft | 7.16 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.31 | ||
| Ballast / displ. | 41.35 % | ||
| Displ. / length | 222.04 | ||
| Comfort ratio | 39.32 | ||
| Capsize | 1.73 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 46 ft | ||
| Maximum draft | 7.16 ft | ||
| Displacement | 48413 lbs | ||
| Ballast | 20018 lbs | ||
| Hull speed | 9.09 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 1431 sq.ft | ||
| Air draft | 73 ft | ||
| Sail area fore | 751.36 sq.ft | ||
| Sail area main | 679.47 sq.ft | ||
| I | 71.90 ft | ||
| J | 20.90 ft | ||
| P | 63.80 ft | ||
| E | 21.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 140 HP | ||
| Fuel capacity | 291 gals |
Accommodations
| Water capacity | 264 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Queen Long Marine | ||
| Designer | German Frers | ||
| First built | 1999 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
