The Hutting 40 is a 39.7ft cutter designed by Dick Koopmans Sr and built in aluminum or steel by Hutting Yachts (NL) since 2000.
It accomodates 6 people in 3 cabins plus salon.
The Hutting 40 is a heavy sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is good. There is a good water supply range.
Main features
| Model | Hutting 40 | ||
| Length | 39.70 ft | ||
| Beam | 11.81 ft | ||
| Draft | 5.25 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 320000 |
Hutting Yachts brochure
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.42 | ||
| Ballast / displ. | 50.75 % | ||
| Displ. / length | 362.35 | ||
| Comfort ratio | 48.53 | ||
| Capsize | 1.53 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Aluminum or Steel | ||
| Waterline length | 33.14 ft | ||
| Maximum draft | 5.25 ft | ||
| Displacement | 29541.91 lbs | ||
| Ballast | 14991.42 lbs | ||
| Hull speed | 7.71 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 861.11 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 448.85 sq.ft | ||
| Sail area main | 409.03 sq.ft | ||
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 56 HP | ||
| Fuel capacity | 132 gals |
Accommodations
| Water capacity | 118.87 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 3 | ||
| Nb of berths | 6 | ||
| Nb heads | 1 |
Builder data
| Builder | Hutting Yachts (NL) | ||
| Designer | Dick Koopmans Sr | ||
| First built | 2000 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
