The Hurley 3090 is a 30.0ft masthead sloop designed by Ian Anderson and built in fiberglass by Hurley Marine Ltd. since 1972.
30 units have been built.
The Hurley 3090 is a moderate weight sailboat which is under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Hurley 3090 | ||
| Length | 30 ft | ||
| Beam | 9.50 ft | ||
| Draft | 4.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 12.83 | ||
| Ballast / displ. | 34 % | ||
| Displ. / length | 254 | ||
| Comfort ratio | 28.32 | ||
| Capsize | 1.77 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 26 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 10000 lbs | ||
| Ballast | 3400 lbs | ||
| Hull speed | 6.83 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 371 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 233.13 sq.ft | ||
| Sail area main | 138.33 sq.ft | ||
| I | 37.30 ft | ||
| J | 12.50 ft | ||
| P | 31.80 ft | ||
| E | 8.70 ft |
Engine
| Nb engines | 1 | ||
| Total power | 12 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 32 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hurley Marine Ltd. | ||
| Designer | Ian Anderson | ||
| First built | 1972 | ||
| Last built | 0 | ?? | |
| Number built | 30 |
