The Hunter 49 is a 49.92ft b&r designed by Glenn Henderson/Hunter Design Team and built in fiberglass by Hunter Marine (USA) since 2007.
The Hunter 49 is a light sailboat which is a high performer. It is stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is good. There is an excellent water supply range.
Main features
| Model | Hunter 49 | ||
| Length | 49.92 ft | ||
| Beam | 14.75 ft | ||
| Draft | 5.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.02 | ||
| Ballast / displ. | 38.23 % | ||
| Displ. / length | 173.97 | ||
| Comfort ratio | 30.84 | ||
| Capsize | 1.85 |
Hull
| Hull type | Monohull wing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 43.83 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 32813 lbs | ||
| Ballast | 12544 lbs | ||
| Hull speed | 8.87 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | B&R | ||
| Sail area (100%) | 1277 sq.ft | ||
| Air draft | 63.33 ft | ||
| Sail area fore | 450.29 sq.ft | ||
| Sail area main | 563 sq.ft | ||
| I | 54.58 ft | ||
| J | 16.50 ft | ||
| P | 51.58 ft | ||
| E | 21.83 ft |
Engine
| Nb engines | 1 | ||
| Total power | 75 HP | ||
| Fuel capacity | 150 gals |
Accommodations
| Water capacity | 200 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hunter Marine (USA) | ||
| Designer | Glenn Henderson/Hunter Design Team | ||
| First built | 2007 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
