The Hunter 420 is a 43.42ft b&r designed by Hunter Design Team and built in fiberglass by Hunter Marine (USA) between 1998 and 2004.
The Hunter 420 is a light sailboat which is a good performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a good water supply range.
Main features
| Model | Hunter 420 | ||
| Length | 43.42 ft | ||
| Beam | 13.83 ft | ||
| Draft | 6.42 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.25 | ||
| Ballast / displ. | 34.36 % | ||
| Displ. / length | 160.80 | ||
| Comfort ratio | 23.08 | ||
| Capsize | 2.06 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 37.83 ft | ||
| Maximum draft | 6.42 ft | ||
| Displacement | 19500 lbs | ||
| Ballast | 6700 lbs | ||
| Hull speed | 8.24 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | B&R | ||
| Sail area (100%) | 823 sq.ft | ||
| Air draft | 61 ft | ||
| Sail area fore | 386.06 sq.ft | ||
| Sail area main | 437.17 sq.ft | ||
| I | 47.75 ft | ||
| J | 16.17 ft | ||
| P | 45.42 ft | ||
| E | 19.25 ft |
Engine
| Nb engines | 1 | ||
| Total power | 50 HP | ||
| Fuel capacity | 13 gals |
Accommodations
| Water capacity | 145 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hunter Marine (USA) | ||
| Designer | Hunter Design Team | ||
| First built | 1998 | ||
| Last built | 2004 | ||
| Number built | 0 | ?? |
