Hunter 31
The Hunter 31 is a 31.33ft b&r designed by Cortland Steck and built in fiberglass by Hunter Marine (USA) between 1983 and 1987.
The Hunter 31 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Hunter 31 for sale elsewhere on the web:
Main features
| Model | Hunter 31 | ||
| Length | 31.33 ft | ||
| Beam | 10.92 ft | ||
| Draft | 5.30 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.17 | ||
| Ballast / displ. | 41.24 % | ||
| Displ. / length | 239.41 | ||
| Comfort ratio | 22.36 | ||
| Capsize | 2.05 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 26.25 ft | ||
| Maximum draft | 5.30 ft | ||
| Displacement | 9700 lbs | ||
| Ballast | 4000 lbs | ||
| Hull speed | 6.87 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | B&R | ||
| Sail area (100%) | 458 sq.ft | ||
| Air draft | 47.33 ft | ||
| Sail area fore | 252 sq.ft | ||
| Sail area main | 205.81 sq.ft | ||
| I | 42 ft | ||
| J | 12 ft | ||
| P | 37.42 ft | ||
| E | 11 ft |
Engine
| Nb engines | 1 | ||
| Total power | 16 HP | ||
| Fuel capacity | 18 gals |
Accommodations
| Water capacity | 33 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hunter Marine (USA) | ||
| Designer | Cortland Steck | ||
| First built | 1983 | ||
| Last built | 1987 | ||
| Number built | 0 | ?? |
