The Hunter 27 edge is a 26.35ft fractional sloop designed by Hunter Design Team and built in fiberglass by Hunter Marine (USA) since 2006.
The Hunter 27 edge is a light sailboat which is a high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Hunter 27 edge | ||
| Length | 26.35 ft | ||
| Beam | 8.33 ft | ||
| Draft | 1.57 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.24 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 108.94 | ||
| Comfort ratio | 12.75 | ||
| Capsize | 2.21 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 24.18 ft | ||
| Maximum draft | 4.92 ft | ||
| Displacement | 3450 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 6.59 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 288 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 135.87 sq.ft | ||
| Sail area main | 152.08 sq.ft | ||
| I | 23.67 ft | ||
| J | 11.48 ft | ||
| P | 24.83 ft | ||
| E | 12.25 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 6 gals |
Accommodations
| Water capacity | 10 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hunter Marine (USA) | ||
| Designer | Hunter Design Team | ||
| First built | 2006 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
