The Holder 14 is a 13.67ft fractional sloop designed by Ron Holder and built in fiberglass by Hobie Cat between 1983 and 1986.
The Holder 14 is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Holder 14 | ||
| Length | 13.67 ft | ||
| Beam | 6.17 ft | ||
| Draft | 0.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 42.70 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 60.57 | ||
| Comfort ratio | 2.82 | ||
| Capsize | 3.84 |
Hull
| Hull type | Centerboard Dinghy | ||
| Construction | Fiberglass | ||
| Waterline length | 12.50 ft | ||
| Maximum draft | 3.82 ft | ||
| Displacement | 265 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 4.74 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 110 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 27.66 sq.ft | ||
| Sail area main | 63.77 sq.ft | ||
| I | 13.30 ft | ||
| J | 4.16 ft | ||
| P | 16.50 ft | ||
| E | 7.73 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hobie Cat | ||
| Designer | Ron Holder | ||
| First built | 1983 | ||
| Last built | 1986 | ||
| Number built | 0 | ?? |
