The Hanse 545 is a 53.15ft fractional sloop designed by Judel/Vrolijk and built in fiberglass by Hanse Yachts since 2008.
The Hanse 545 is a light sailboat which is a good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is good. There is a good water supply range.
Main features
| Model | Hanse 545 | ||
| Length | 53.15 ft | ||
| Beam | 16.11 ft | ||
| Draft | 9.19 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.48 | ||
| Ballast / displ. | 31.02 % | ||
| Displ. / length | 167.46 | ||
| Comfort ratio | 31.80 | ||
| Capsize | 1.87 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 47.90 ft | ||
| Maximum draft | 9.19 ft | ||
| Displacement | 41226 lbs | ||
| Ballast | 12787 lbs | ||
| Hull speed | 9.27 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1447 sq.ft | ||
| Air draft | 86.20 ft | ||
| Sail area fore | 696.50 sq.ft | ||
| Sail area main | 750.50 sq.ft | ||
| I | 69.72 ft | ||
| J | 19.98 ft | ||
| P | 70.37 ft | ||
| E | 21.33 ft |
Engine
| Nb engines | 1 | ||
| Total power | 110 HP | ||
| Fuel capacity | 106 gals |
Accommodations
| Water capacity | 185 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hanse Yachts | ||
| Designer | Judel/Vrolijk | ||
| First built | 2008 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
