The Hanse 505 is a 50.2ft fractional sloop designed by Judel/Vrolijk and built in fiberglass by Hanse Yachts since 2012.
The Hanse 505 is a light sailboat which is a high performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Hanse 505 | ||
| Length | 50.20 ft | ||
| Beam | 15.58 ft | ||
| Draft | 7.81 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.53 | ||
| Ballast / displ. | 27.81 % | ||
| Displ. / length | 164.91 | ||
| Comfort ratio | 27.57 | ||
| Capsize | 1.97 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 44.13 ft | ||
| Maximum draft | 7.81 ft | ||
| Displacement | 31747 lbs | ||
| Ballast | 8830 lbs | ||
| Hull speed | 8.90 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1281 sq.ft | ||
| Air draft | 72.50 ft | ||
| Sail area fore | 614.65 sq.ft | ||
| Sail area main | 607.32 sq.ft | ||
| I | 64.16 ft | ||
| J | 19.16 ft | ||
| P | 60.25 ft | ||
| E | 20.16 ft |
Engine
| Nb engines | 1 | ||
| Total power | 72 HP | ||
| Fuel capacity | 74 gals |
Accommodations
| Water capacity | 166 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hanse Yachts | ||
| Designer | Judel/Vrolijk | ||
| First built | 2012 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
