Arpege 30 dufour
The Arpege 30 dufour is a 30.0ft masthead sloop designed by Michel Dufour and built in fiberglass by Dufour Yachts (FRA) between 1966 and 1976.
1500 units have been built.
The Arpege 30 dufour is a heavy sailboat which is slightly under powered. It is stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser.
Arpege 30 dufour for sale elsewhere on the web:
Main features
| Model | Arpege 30 dufour | ||
| Length | 30 ft | ||
| Beam | 9.92 ft | ||
| Draft | 4.60 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.74 | ||
| Ballast / displ. | 39.61 % | ||
| Displ. / length | 322.83 | ||
| Comfort ratio | 22.95 | ||
| Capsize | 2.01 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 22 ft | ||
| Maximum draft | 4.60 ft | ||
| Displacement | 7700 lbs | ||
| Ballast | 3050 lbs | ||
| Hull speed | 6.29 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 382 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 198.22 sq.ft | ||
| Sail area main | 184.08 sq.ft | ||
| I | 37.40 ft | ||
| J | 10.60 ft | ||
| P | 31.20 ft | ||
| E | 11.80 ft |
Engine
| Nb engines | 1 | ||
| Total power | 15 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Dufour Yachts (FRA) | ||
| Designer | Michel Dufour | ||
| First built | 1966 | ||
| Last built | 1976 | ||
| Number built | 1500 |
