The Hallberg rassy 40 mk2 is a 40.68ft masthead sloop designed by German Frers and built in fiberglass by Hallberg Rassy since 2015.
The Hallberg rassy 40 mk2 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is good. There is a good water supply range.
Main features
| Model | Hallberg rassy 40 mk2 | ||
| Length | 40.68 ft | ||
| Beam | 12.53 ft | ||
| Draft | 6.53 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.82 | ||
| Ballast / displ. | 37.27 % | ||
| Displ. / length | 225.40 | ||
| Comfort ratio | 34.34 | ||
| Capsize | 1.74 |
Hull
| Hull type | Monohull fin keel with rudder on partial skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 36.35 ft | ||
| Maximum draft | 6.53 ft | ||
| Displacement | 24250.82 lbs | ||
| Ballast | 9038.94 lbs | ||
| Hull speed | 8.08 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 877.04 sq.ft | ||
| Air draft | 60.86 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 60 HP | ||
| Fuel capacity | 118 gals |
Accommodations
| Water capacity | 122 gals | ||
| Headroom | 6.30 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hallberg Rassy | ||
| Designer | German Frers | ||
| First built | 2015 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
