Hallberg rassy 29
The Hallberg rassy 29 is a 29.17ft masthead sloop designed by Olle Enderlein / Christoph Rassy and built in fiberglass by Hallberg Rassy between 1982 and 1994.
571 units have been built.
The Hallberg rassy 29 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
See all sailboats built by Hallberg Rassy
See all sailboats designed by Olle Enderlein / Christoph Rassy
Hallberg rassy 29 for sale elsewhere on the web:
Main features
| Model | Hallberg rassy 29 | ||
| Length | 29.17 ft | ||
| Beam | 9.25 ft | ||
| Draft | 5.25 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.25 | ||
| Ballast / displ. | 46.06 % | ||
| Displ. / length | 277.50 | ||
| Comfort ratio | 26.32 | ||
| Capsize | 1.82 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 23.80 ft | ||
| Maximum draft | 5.25 ft | ||
| Displacement | 8380 lbs | ||
| Ballast | 3860 lbs | ||
| Hull speed | 6.54 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 392 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 211.05 sq.ft | ||
| Sail area main | 181.13 sq.ft | ||
| I | 12.60 ft | ||
| J | 33.50 ft | ||
| P | 34.50 ft | ||
| E | 10.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 16 gals |
Accommodations
| Water capacity | 32 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Hallberg Rassy | ||
| Designer | Olle Enderlein / Christoph Rassy | ||
| First built | 1982 | ||
| Last built | 1994 | ||
| Number built | 571 |
