Halcyon 23
The Halcyon 23 is a 22.75ft masthead sloop designed by Alan Buchanan and built in fiberglass by Offshore Yachts Ltd. (UK) since 1967.
1000 units have been built.
The Halcyon 23 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Halcyon 23 for sale elsewhere on the web:
Main features
| Model | Halcyon 23 | ||
| Length | 22.75 ft | ||
| Beam | 7.50 ft | ||
| Draft | 2.25 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.98 | ||
| Ballast / displ. | 37.26 % | ||
| Displ. / length | 212.66 | ||
| Comfort ratio | 16.44 | ||
| Capsize | 2.06 |
Hull
| Hull type | Monohull triple Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 18.67 ft | ||
| Maximum draft | 2.25 ft | ||
| Displacement | 3100 lbs | ||
| Ballast | 1155 lbs | ||
| Hull speed | 5.79 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 225 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 10 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Offshore Yachts Ltd. (UK) | ||
| Designer | Alan Buchanan | ||
| First built | 1967 | ||
| Last built | 0 | ?? | |
| Number built | 1000 |
Other photos
