The Gulfstar 40 hood is a 40.17ft masthead sloop designed by Ted Hood and built in fiberglass by Gulfstar Yachts between 1976 and 1978.
19 units have been built.
The Gulfstar 40 hood is a heavy sailboat which is slightly under powered. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Gulfstar 40 hood | ||
| Length | 40.17 ft | ||
| Beam | 11.33 ft | ||
| Draft | 3.92 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.79 | ||
| Ballast / displ. | 52.08 % | ||
| Displ. / length | 317.06 | ||
| Comfort ratio | 42.18 | ||
| Capsize | 1.57 |
Hull
| Hull type | Monohull keel and centerboard with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 32.33 ft | ||
| Maximum draft | 11.33 ft | ||
| Displacement | 24000 lbs | ||
| Ballast | 12500 lbs | ||
| Hull speed | 7.62 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 766 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 445.20 sq.ft | ||
| Sail area main | 319.69 sq.ft | ||
| I | 53 ft | ||
| J | 16.80 ft | ||
| P | 46.50 ft | ||
| E | 13.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 50 HP | ||
| Fuel capacity | 65 gals |
Accommodations
| Water capacity | 125 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Gulfstar Yachts | ||
| Designer | Ted Hood | ||
| First built | 1976 | ||
| Last built | 1978 | ||
| Number built | 19 |
