Gecco 39
The Gecco 39 is a 39.01ft masthead sloop designed by Magnus Öster/Bo Jonsson and built in fiberglass between 1980 and 1990.
The Gecco 39 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Gecco 39 for sale elsewhere on the web:
Main features
| Model | Gecco 39 | ||
| Length | 39.01 ft | ||
| Beam | 11.88 ft | ||
| Draft | 6.73 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.63 | ||
| Ballast / displ. | 46.67 % | ||
| Displ. / length | 277.24 | ||
| Comfort ratio | 29.02 | ||
| Capsize | 1.87 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 29.86 ft | ||
| Maximum draft | 6.73 ft | ||
| Displacement | 16534 lbs | ||
| Ballast | 7716 lbs | ||
| Hull speed | 7.32 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 672 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 389.01 sq.ft | ||
| Sail area main | 283.32 sq.ft | ||
| I | 49.21 ft | ||
| J | 15.81 ft | ||
| P | 45.44 ft | ||
| E | 12.47 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 34 gals |
Accommodations
| Water capacity | 66 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Magnus Öster/Bo Jonsson | ||
| First built | 1980 | ||
| Last built | 1990 | ||
| Number built | 0 | ?? |
