The Freedom 36 is a 36.42ft fractional sloop (free standing) designed by Gary Mull and built in fiberglass by Freedom Yachts since 1985.
The Freedom 36 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Freedom 36 | ||
| Length | 36.42 ft | ||
| Beam | 12.50 ft | ||
| Draft | 4.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.61 | ||
| Ballast / displ. | 45.23 % | ||
| Displ. / length | 223.24 | ||
| Comfort ratio | 23.74 | ||
| Capsize | 2.06 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 30.63 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 14370 lbs | ||
| Ballast | 6500 lbs | ||
| Hull speed | 7.42 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop (Free standing) | ||
| Sail area (100%) | 685 sq.ft | ||
| Air draft | 55.50 ft | ||
| Sail area fore | 191.71 sq.ft | ||
| Sail area main | 376.97 sq.ft | ||
| I | 33.34 ft | ||
| J | 11.50 ft | ||
| P | 45.50 ft | ||
| E | 16.57 ft |
Engine
| Nb engines | 1 | ||
| Total power | 27 HP | ||
| Fuel capacity | 35 gals |
Accommodations
| Water capacity | 64 gals | ||
| Headroom | 6.33 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Freedom Yachts | ||
| Designer | Gary Mull | ||
| First built | 1985 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
