The Freedom 28 cat ketch is a 28.33ft cat ketch (unstayed) designed by Gary Hoyt/Jay Paris and built in fiberglass by Freedom Yachts since 1979.
The Freedom 28 cat ketch is a light sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Freedom 28 cat ketch | ||
| Length | 28.33 ft | ||
| Beam | 9.33 ft | ||
| Draft | 2.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.33 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 183.03 | ||
| Comfort ratio | 20.83 | ||
| Capsize | 1.95 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 25.75 ft | ||
| Maximum draft | 5.33 ft | ||
| Displacement | 7000 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 6.80 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cat Ketch (unstayed) | ||
| Sail area (100%) | 395 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 15 HP | ||
| Fuel capacity | 18 gals |
Accommodations
| Water capacity | 30 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Freedom Yachts | ||
| Designer | Gary Hoyt/Jay Paris | ||
| First built | 1979 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
