The Apogee 50 paine is a 51.0ft cutter designed by Chuck Paine and built in carbon fiber or composite by Morris Yachts since 1995.
The Apogee 50 paine is a light sailboat which is a reasonably good performer. It is stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat.
Main features
| Model | Apogee 50 paine | ||
| Length | 51 ft | ||
| Beam | 14 ft | ||
| Draft | 6 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.49 | ||
| Ballast / displ. | 35.63 % | ||
| Displ. / length | 149.97 | ||
| Comfort ratio | 31.14 | ||
| Capsize | 1.77 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 45.67 ft | ||
| Maximum draft | 6 ft | ||
| Displacement | 32000 lbs | ||
| Ballast | 11400 lbs | ||
| Hull speed | 9.06 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 1068 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 586.95 sq.ft | ||
| Sail area main | 510.40 sq.ft | ||
| I | 64.50 ft | ||
| J | 18.20 ft | ||
| P | 58 ft | ||
| E | 17.60 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Morris Yachts | ||
| Designer | Chuck Paine | ||
| First built | 1995 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
