The Expo 142 catalina is a 15.16ft cat (unstayed) designed by Hoyt and built in fiberglass by Catalina Yachts since 1997.
The Expo 142 catalina is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Expo 142 catalina | ||
| Length | 15.16 ft | ||
| Beam | 6.16 ft | ||
| Draft | 0.33 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 34.20 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 65.25 | ||
| Comfort ratio | 3.37 | ||
| Capsize | 3.53 |
Hull
| Hull type | Daggerboard dinghy | ||
| Construction | Fiberglass | ||
| Waterline length | 13.25 ft | ||
| Maximum draft | 3.50 ft | ||
| Displacement | 340 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 4.88 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cat (unstayed) | ||
| Sail area (100%) | 104 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 104.13 sq.ft | ||
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 20.16 ft | ||
| E | 10.33 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Catalina Yachts | ||
| Designer | Hoyt | ||
| First built | 1997 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
