Evelyn 26
The Evelyn 26 is a 26.0ft fractional sloop designed by Bob Evelyn and built in fiberglass by Formula Yachts (USA) since 1980.
75 units have been built.
The Evelyn 26 is a light sailboat which is a high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Evelyn 26 for sale elsewhere on the web:
Main features
| Model | Evelyn 26 | ||
| Length | 26 ft | ||
| Beam | 9.50 ft | ||
| Draft | 4.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.22 | ||
| Ballast / displ. | 33.33 % | ||
| Displ. / length | 188.66 | ||
| Comfort ratio | 14.16 | ||
| Capsize | 2.36 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21.50 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 4200 lbs | ||
| Ballast | 1400 lbs | ||
| Hull speed | 6.21 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 328 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 137.75 sq.ft | ||
| Sail area main | 187.74 sq.ft | ||
| I | 29 ft | ||
| J | 9.50 ft | ||
| P | 29.80 ft | ||
| E | 12.60 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Formula Yachts (USA) | ||
| Designer | Bob Evelyn | ||
| First built | 1980 | ||
| Last built | 0 | ?? | |
| Number built | 75 |
Other photos
