Endeavour 33
The Endeavour 33 is a 33.0ft masthead sloop designed by Bruce Kelley and built in fiberglass by Endeavour Yacht Corp. (USA) between 1983 and 1986.
The Endeavour 33 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a very short water supply range.
Endeavour 33 for sale elsewhere on the web:
Main features
| Model | Endeavour 33 | ||
| Length | 33 ft | ||
| Beam | 11.50 ft | ||
| Draft | 4.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.13 | ||
| Ballast / displ. | 40.53 % | ||
| Displ. / length | 243.64 | ||
| Comfort ratio | 23.27 | ||
| Capsize | 2.05 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 27.50 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 11350 lbs | ||
| Ballast | 4600 lbs | ||
| Hull speed | 7.03 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 539 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 310.95 sq.ft | ||
| Sail area main | 228.54 sq.ft | ||
| I | 45 ft | ||
| J | 13.82 ft | ||
| P | 39 ft | ||
| E | 11.72 ft |
Engine
| Nb engines | 1 | ||
| Total power | 22 HP | ||
| Fuel capacity | 36 gals |
Accommodations
| Water capacity | 36 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Endeavour Yacht Corp. (USA) | ||
| Designer | Bruce Kelley | ||
| First built | 1983 | ||
| Last built | 1986 | ||
| Number built | 0 | ?? |
Other photos
