The Eagle 54 is a 54.59ft fractional sloop designed by Hoek Design and built in fiberglass epoxy with foam core by Leonardo Yachts (NL) since 2017.
The Eagle 54 is a light sailboat which is a very high performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a cruiser racer. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Eagle 54 | ||
| Length | 54.59 ft | ||
| Beam | 10.73 ft | ||
| Draft | 9.19 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 30.50 | ||
| Ballast / displ. | 41.17 % | ||
| Displ. / length | 193.71 | ||
| Comfort ratio | 31.40 | ||
| Capsize | 1.59 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass epoxy with foam core | ||
| Waterline length | 35.76 ft | ||
| Maximum draft | 9.19 ft | ||
| Displacement | 19842 lbs | ||
| Ballast | 8168 lbs | ||
| Hull speed | 8.01 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1391.77 sq.ft | ||
| Air draft | 66.60 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 39 HP | ||
| Fuel capacity | 40 gals |
Accommodations
| Water capacity | 49 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Leonardo Yachts (NL) | ||
| Designer | Hoek Design | ||
| First built | 2017 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
