Dolphin 81
The Dolphin 81 is a 26.57ft fractional sloop designed by Ettore Santarelli and built in fiberglass by Maxi Dolphin Boatyard (ITA) since 1992.
The Dolphin 81 is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Dolphin 81 for sale elsewhere on the web:
Main features
| Model | Dolphin 81 | ||
| Length | 26.57 ft | ||
| Beam | 8.86 ft | ||
| Draft | 5.25 ft | ||
| Country | Italy (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 37.92 | ||
| Ballast / displ. | 44.22 % | ||
| Displ. / length | 68.05 | ||
| Comfort ratio | 7.16 | ||
| Capsize | 2.77 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23.95 ft | ||
| Maximum draft | 5.25 ft | ||
| Displacement | 2094 lbs | ||
| Ballast | 926 lbs | ||
| Hull speed | 6.56 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 387 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Maxi Dolphin Boatyard (ITA) | ||
| Designer | Ettore Santarelli | ||
| First built | 1992 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
