Dehler 43 cws
The Dehler 43 cws is a 43.31ft fractional sloop designed by Van de Stadt and built in fiberglass by Dehler Yachts since 1995.
The Dehler 43 cws is a moderate weight sailboat which is a very high performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is originally small. There is a good water supply range.
Dehler 43 cws for sale elsewhere on the web:
Main features
| Model | Dehler 43 cws | ||
| Length | 43.31 ft | ||
| Beam | 12.80 ft | ||
| Draft | 6.73 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.19 | ||
| Ballast / displ. | 43.68 % | ||
| Displ. / length | 203.52 | ||
| Comfort ratio | 26.62 | ||
| Capsize | 1.92 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 34.78 ft | ||
| Maximum draft | 6.73 ft | ||
| Displacement | 19180 lbs | ||
| Ballast | 8377 lbs | ||
| Hull speed | 7.90 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 990 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 48 HP | ||
| Fuel capacity | 40 gals |
Accommodations
| Water capacity | 106 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Dehler Yachts | ||
| Designer | Van de Stadt | ||
| First built | 1995 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
