The Dehler 25 is a 24.77ft fractional sloop designed by E. G. van de Stadt and built in fiberglass by Dehler Yachts between 1984 and 1995.
350 units have been built.
The Dehler 25 is a light sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Dehler 25 | ||
| Length | 24.77 ft | ||
| Beam | 8.27 ft | ||
| Draft | 1.30 ft | ||
| Country | Germany (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.59 | ||
| Ballast / displ. | 45.86 % | ||
| Displ. / length | 139.25 | ||
| Comfort ratio | 13.24 | ||
| Capsize | 2.24 |
Hull
| Hull type | Monohull lifting keel | ||
| Construction | Fiberglass | ||
| Waterline length | 21.83 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 3245 lbs | ||
| Ballast | 1488 lbs | ||
| Hull speed | 6.26 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 254 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 98.63 sq.ft | ||
| Sail area main | 155.52 sq.ft | ||
| I | 26.30 ft | ||
| J | 7.50 ft | ||
| P | 28.80 ft | ||
| E | 10.80 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 10 gals |
Accommodations
| Water capacity | 19 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Dehler Yachts | ||
| Designer | E. G. van de Stadt | ||
| First built | 1984 | ||
| Last built | 1995 | ||
| Number built | 350 |
Other photos
