The Cs 40 is a 39.25ft masthead sloop designed by Tony Castro and built in fiberglass by CS Yachts (Canadian Sailcraft) since 1987.
The Cs 40 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Cs 40 | ||
| Length | 39.25 ft | ||
| Beam | 12.67 ft | ||
| Draft | 6.58 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.61 | ||
| Ballast / displ. | 44.12 % | ||
| Displ. / length | 217.65 | ||
| Comfort ratio | 25.78 | ||
| Capsize | 1.97 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 32.67 ft | ||
| Maximum draft | 6.58 ft | ||
| Displacement | 17000 lbs | ||
| Ballast | 7500 lbs | ||
| Hull speed | 7.66 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 766 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 395.25 sq.ft | ||
| Sail area main | 371.25 sq.ft | ||
| I | 51 ft | ||
| J | 15.50 ft | ||
| P | 45 ft | ||
| E | 16.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 43 HP | ||
| Fuel capacity | 50 gals |
Accommodations
| Water capacity | 100 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | CS Yachts (Canadian Sailcraft) | ||
| Designer | Tony Castro | ||
| First built | 1987 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
