The Columbia 57 is a 56.5ft masthead sloop designed by William Tripp Jr. and built in fiberglass by Columbia Yachts between 1969 and 1974.
11 units have been built.
It accomodates 7 people in 2 cabins plus salon.
The Columbia 57 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is excellent.
Main features
| Model | Columbia 57 | ||
| Length | 56.50 ft | ||
| Beam | 13 ft | ||
| Draft | 8 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 50000 |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.42 | ||
| Ballast / displ. | 48.89 % | ||
| Displ. / length | 298.64 | ||
| Comfort ratio | 50.29 | ||
| Capsize | 1.47 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 40.67 ft | ||
| Maximum draft | 8 ft | ||
| Displacement | 45000 lbs | ||
| Ballast | 22000 lbs | ||
| Hull speed | 8.55 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 1293 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 690.80 sq.ft | ||
| Sail area main | 602 sq.ft | ||
| I | 62.80 ft | ||
| J | 22 ft | ||
| P | 56 ft | ||
| E | 21.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 130 HP | ||
| Fuel capacity | 216 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 2 | ||
| Nb of berths | 7 | ||
| Nb heads | 1 |
Builder data
| Builder | Columbia Yachts | ||
| Designer | William Tripp Jr. | ||
| First built | 1969 | ||
| Last built | 1974 | ||
| Number built | 11 |
